3G SDI 1080P Box Camera 2MP 60fps/50fps 3.2mm Fixed Lens Industrial SDI
Product Description
This 3G HD-SDI 2.0MP industrial box camera delivers true 1080P (1920×1080) high-definition video with smooth 60fps/50fps high frame rate for real-time monitoring. Adopting a high-performance CMOS sensor, it provides sharp and clear imaging for industrial security, machine vision, production line monitoring, and professional surveillance scenarios.
With a wide operating temperature range (-10℃ to +50℃) and durable box-type design, this camera is built for 24/7 industrial use. It supports multiple frame rates and TV systems (PAL/NTSC), making it a versatile solution for global industrial and security applications.
Key Features
- 2.0MP high-performance sensor, true 1080P (1920×1080) resolution
- Up to 60fps/50fps high frame rate for smooth real-time video
- 3G HD-SDI + CVBS dual output, wide compatibility
- 3.2mm fixed lens for stable and clear monitoring
- WDR, 3D-DNR, HLC, BLC, defog for clear imaging
- OSD menu, motion detection, privacy zone, D-ZOOM
- PAL/NTSC switchable, mirror/flip function
- Box-type structure for industrial installation
- Wide operating temperature: -10℃ to +50℃
- DC 12V power supply, stable long-time working
Package Includes
1 x 3G HD-SDI 1080P 2.0MP Industrial Box Security Camera
Product overview
2.0Mega Pixel SONY IMX 290+ Eyenix 778
1080p(1920x1080)@NTSC 60fps/30fps PAL 50fps / 25fps(You can choose from the menu)
Support WDR,3D-DNR
Defog:Use this function in the fog weather.
OSD menu,Motion detection,Privacy Zone,HLC,BLC
TV Out(BNC) with NTSC/PAL Selectable
Dual Output-Megapixel HD-SDI(BNC)&CVBS:1.0 Vp-p 75ohm
Technical parameters
| Model No. |
OSY-SDI-60 3.2MM LENS
|
||||||
| Image Sensor | 2.0Mega Pixel,Panasonic V34229 +Eyenix 778 | ||||||
| Effective pixels | 1920(H) x 1080(V) | ||||||
| Scanning system | Progressive Scan | ||||||
| Minimum illumination | 0.2 Lux(Color/Day) 0.01Lux(B/W) | ||||||
| Lens | 3.2mm | ||||||
| IR view distance | N/A | ||||||
| WDR (Long and Short exposure) | OFF/ON(Level Adjustable) | ||||||
| O.S.D | Built-in | ||||||
| 3D-DNR (3D Digital Noise Reduction) | OFF/ON(LOW/MIDDLE/HIGH) | ||||||
| Sens-Up | OFF/ON | ||||||
| Motion Detection | OFF/ON | ||||||
| Privacy Zone | OFF/ON | ||||||
| HLC | OFF/ON | ||||||
| B.L.C. control | OFF/ON | ||||||
| Defog | OFF/ON | ||||||
| White balance | AWB/ATW/PUSH/MANUAL | ||||||
| A.G.C | HIGH / LOW | ||||||
| D-ZOOM | 1.0x - 8.0x | ||||||
| MIRROR | OFF/ON | ||||||
| FLIP | OFF/ON | ||||||
| TV system | PAL/NTSC | ||||||
| Electronic shutter Speed | AUTO/MANUAL/FLK | ||||||
| Video output | HD-SDI(SMPTE 292M compatible) / CVBS:1.0 Vp-p Composite Signal (75ohm) | ||||||
| Operation temperature | -10℃ - +50℃ | ||||||
| Operation Humidity | Within 95% RH | ||||||
| Power supply | DC12V(+/-15%) | ||||||
| Power Consumption | 1000mA | ||||||
